The Stretch Film Slitter Rewinder Machine is used to produce winding film, also known as packaging film or stretching film. Mainly used for producing various specifications and thicknesses of winding films to meet the packaging needs of different industries.
| 500mm stretching film machine | ||
|
MODEL |
GT-55-500 |
GT-55/55-500 |
|
Screw diameter |
55mm |
55x 2mm |
|
L/D ratio of screw |
30:1 |
30:1 |
|
Width of T-Die |
650mm |
650mm |
|
Width of film |
500mm |
500mm |
|
Thichness of film |
0.01-0.05mm |
0.01-0.05mm |
|
Structure of film layers |
A |
A/B |
|
Max output |
25-40kg/h |
35-55kg/h |
|
Linear speed of machinery |
50-100m/min |
50-100m/min |
|
Total power |
40kw |
65kw |
|
Dimension(LxWxH) |
7x4x3m |
7x4x3m |
|
Weight(about) |
3T |
4T |
Enhanced tensile strength, puncture resistance, and impact durability: GUOTAI machine manufactured stretch packaging can withstand the strict requirements of transportation and handling. This strength ensures that the film can firmly secure and protect the goods under various conditions without tearing or puncturing, providing peace of mind during transportation and storage.
High clarity and extensibility: making the packaged goods visually attractive while facilitating identification and inspection
