GT-600

PE Film Blowing Machine

The GUOTAI PE film blowing machine is a versatile and efficient solution designed to meet the diverse needs of the packaging industry. Engineered with precision and excellence, this machine is adept at producing a wide range of films suitable for general packaging...

SUBMIT INQUIRY

Product Description
Main Technical Parameters
Product Highlights

Product Description

Guotai PE blow film machine is a multifunctional and efficient machinery that can meet various needs of the packaging industry.

upload/1c/202503/blown-film-machine-s4.jpg

upload/1c/202503/blown-film-machine-s5.jpg

Main Technical
Parameters

Model	GT-600	GT-700	GT-800
Screw Diameter	Φ65	Φ70	Φ75
Screw Ratio L/D	28:1	28:1	28:1
Screw Speed	15-100r/min	15-100r/min	15-100r/min
Main Motor Power	22kw	30kw	37kw
Main Output	65kg/h	85kg/h	95kg/h
Single-sided Thickness of Film	0.006-0.08mm	0.006-0.08 mm	0.006-0.08 mm
Max. Folding Width of Film	550mm*2	650mm*2	800mm*2
Total Power	40kw	55kw	70kw
Overall Dimension	500029003800mm	530032004700mm	560034004700mm
Weight of Machine	3T	3.8T	4.5T

Product Highlights

Guotai PE blow film machine has advanced technology and can produce symmetrical thin films with uniform thickness and excellent mechanical properties

Guotai PE blow film machine allows for precise adjustment of the machine during the production process to adapt to different material specifications and production parameters, and flexibly solve any problems in various production processes.
