The characteristic of Guotai PVC blow molding machine is the innovative use of high-speed screw structure. Operate the Guotai PVC blow molding machine under high pressure and high speed to ensure effective and uniform plasticization of PVC materials.
| Model | GT-45x2-600 |
| Suitable Material | HDPE/LDPE/LLDPE |
| Max Film Width(mm) | 600 |
| Film Thickness(mm) | HD:0.008-0.08 |
| Max Extrusion Output HD | 55kg/hr |
| Extrusion Unit | |
| Gear Box | 2*146 |
| Screw Diameter(mm) | φ45*2 |
| Screw's Material | 38 CRMOALA |
| Barrel's Material | 38 CRMOALA |
| Barrel's Cooling Fan | 250W*2*2 |
| Thermo Control (zone) | 3 |
| Driving Motor (kw) | 11*2 |
| Extrusion Die | |
| Die Size (mm) | HD:φ60 |
| Screen changer | Standard manual |
| Thermo Control(zone) | 2 |
| Air Ring | φ620 |
| Cooling Blower(kw) | 2.2 |
| Center steady stick | 1 pcs |
| Take-up Unit | |
| Roller Width(mm) | φ138*650 |
| Embossing roller width | 550mm |
| Take-UP Motor (kw) | 0.75 |
| Take-UP Speed(M/min) | 10-80 |
| Height adjustable type | 700mm |
| Winding Unit | |
| Type of Winder | Surface friction winder |
| Roller Width (mm) | 700 |
| Winding Motor(KW) | 6 |
| Winding Speed(M/min) | 10-80 |
| Voltage | 380V/50HZ/3PHASE |
| Cover Dimensins | 4*3*4.3m |
The screw channel of Guotai PVC blow molding machine has self-cleaning ability. If the residual materials in the extruder are not cleaned in time, they will accumulate and may cause machine blockage. Ordinary machines require frequent shutdowns for cleaning and maintenance. The high-speed screws of GUOTAI machines effectively solve this problem, ensuring that each channel is free of debris and improving production efficiency.
